PRODUCTS
Primary raw materials like chrome ore and manganese ores are used for manufacturing different grades of Ferro alloys, refractories, chemicals etc. Depending on their characteristics are in great demand. The ores produced/ traded by the Group are much suited for bulk Ferro alloys producers like Ferro Chrome, Ferro Manganese and Silico Manganese.
Apart from chrome and manganese ore, the Group also trades in other primary raw materials and commodities viz.
Low silica lime stone
Gypsum
Pyroxenite
Sugarcane Molasses
Bitumen
Quartz
Material Specification
| CHROME ORE SPECIFICATION- DIFFERENT ORIGIN QUALITY WISE | ||||||
| CHEMICAL PARAMETERS | RANGE | Low Grade | Medium Grade | High Grade | ||
| Cr2O3 | Qualtiy | 24-34% | 36-40% | 40-44% | 40-44% | 40-42% |
| SiO2 | MAX | 15-18% | 12-15% | 6-10% | 6-10% | 8% |
| P | MAX | 0.01% | 0.01% | 0.01% | 0.01% | 0.01% |
| S | MAX | 0.01% | 0.01% | 0.01% | 0.01% | 0.01% |
| Al2O3 | MAX | 15-22% | 15-22% | 8-10% | 8-12% | 10-12% |
| MgO | MAX | 20-26% | 18-24% | 22-26% | 20-23% | 15-20% |
| Cr:Fe Ratio | MIN | 1.4:1 - 2.2:1 | 2.2:1 - 2.4:1 | 2.4:1 - 2.9:1 | 2.5:1 - 2.9:1% | 1.2:1 - 1.4:1% |
| PHYSICAL SIZE | MIN | 10-300 MM 90% | 10-300 MM 90% | 10-300 MM 80% | 10-300 MM 70% | 0-1 MM 90% |
| PYROXINITE ORE SPECIFICATION,OMAN | ||
| CHEMICAL PARAMETERS | RANGE | Result in % |
| MgO | Min | 38-42% |
| SiO2 | Min | 38-43% |
| Al2O3 | MAX | 1% |
| CaO | MAX | <1.5 |
| PHYSICAL SIZE | MIN | 10-100mm 90% |
| BITUMEN SPECIFICATION,OMAN | ||
| CHEMICAL PARAMETERS | GRADE | |
| Density 25°C (Kg/M³) | 1.010-1.060 | |
| Penetration 25°C (mm/10) | 60-70 | |
| Softeing Point (°C) | 49-56 | |
| Flash Point (° C) | >250°C | |
| MANGANESE ORE SPECIFICATION- DIFFERENT ORIGIN QUALITY WISE | ||||||
| CHEMICAL PARAMETERS | RANGE | Low Grade | Medium Grade | High Grade | ||
| Mn | Qualtiy | 30-34% | 35-39% | 44-50% | 48-50% | |
| SiO2 | MAX | 10-16% | 6-12% | 6-12% | 10-18% | |
| P | MAX | 0.06-0.15% | 0.04-0.16% | 0.25% | <0.001% | |
| S | MAX | 0.05% | <0.01 | <0.01% | <0.01% | |
| Al2O3 | MAX | 6-8% | 2-8% | 6-14% | 1.5-2.5% | |
| Fe | MAX | 9-13% | 5-16% | 3-8% | 4% | |
| MgO | MAX | 0.1% | ||||
| Physical Size | MIN | 6.5-80MM 70% | 10-150 | 10-100 | ||
| GYPSUM ORE SPECIFICATION,OMAN | ||
| Grade Constituents | TYPE 1% | TYPE 2% |
| Combine Water | 19.90 Min | 19.6-19.9 |
| CaSo4 2 H2O | 95 Min | 94 Min |
| CaO | 30 - 5-33 | 30 - 5-33 |
| So4 | 43 - 5-46 | 43 - 5-46 |
| MgO | 0.10 Max | 0.10 Max |
| Al2O3= Fe2O3 | 0.25 Max | 0.25 Max |
| QUARTZ ORE SPECIFICATION,OMAN | ||
| Components | Grade-1 | Grade-2 |
| LOI (Max | 0.5 | 0.5 |
| SiO2 (Min) | 99 | 98.5 |
| Fe2O3 (Max) | 0.02 | 0.04 |
| Al2O3 (Max) | ||
| TiO2 (Max) | 0.01 | 0.01 |
